Despite its compact size, the Mersin model delivers powerful performance. With 21.5-inch and 24-inch screen options and an integrated shelf system, this model efficiently handles a wide range of transactions, from simple purchases to complex multi-item orders. Optional shelves allow for the display of brochures, product samples, or promotional materials, further enhancing the customer experience. Its intuitive interface ensures a seamless process for customers, shortens the learning curve, and minimizes the need for staff assistance. This combination of efficiency, versatility, and ease of use significantly reduces queue times while helping to increase customer satisfaction.
1080 x 1920
500 cd/m²
7/24 50.000 Hour
Key Features
24/7 Industrial Grade Displays
Sleek Design
Manufactured in Türkiye
Customizable
Android and Windows Compatible
High Brightness with Vibrant Colors
General Overview
Operational Speed and Efficiency
Smart Design, Seamless Operation
The Mersin series is engineered to handle transaction flow and eliminate waiting times.
✔Flexible Display: 21.5″ and 24″ touchscreen panel options
✔Compact Power: High performance in limited spaces
✔Zero Waiting: Instant confirmation with a fast processor
User Experience and Flexibility
✔Intuitive Interface: Easy to use without staff assistance
✔Brand Alignment: Software customizable to your brand identity
✔Integrated Shelf System: Extra space for promotions and sample products
Payment Technologies and Security
A technology infrastructure focused on security, compatible with all payment methods.
✔Hybrid Payment: Card, mobile, and secure payment options
✔Built-in Printer: Instant receipt and order confirmation
✔Advanced Security: Integrated operational security systems
Integration and Adaptability
✔Easy Integration: Effortlessly connects to your current infrastructure
✔Versatile Use: Suitable for every sector from supermarkets to retail stores
✔Low Maintenance: Reliable technology minimizing downtime
Technical Specifications
Panel
Panel Size | Resolution | Brightness (Typ.) | Contrast | Viewing Angle (H x V) | Response Angle (G-to-G) | Active Display Area (mm) |
|---|---|---|---|---|---|---|
21.5 | 1080 x 1920 | 500 cd/m² | 1300:1 (Typ.) (TM) | 178° x 178° | 14 ms (G to G) | 476.00 (H) x 268.00 (V) |
Touch Screen
Touch Technology | Touch Points | Glass Hardness |
|---|---|---|
Projected Capacitive | 10 points Multi-touch | 6H (min.) |
Internal Player (Optional)
CPU | RAM | HDD | OS | I/O |
|---|---|---|---|---|
Quad Core | 4GB | 32GB | Android 11 | HDMI, USB, ETHERNET, WiFi |
Power
Power Requirement | Power Consumption (Avg.) | Standby Mode |
|---|---|---|
AC 100 - 240 V~ (+/- 10 %) 50/60 Hz | 32W | <0,5W |
Operations
Operation Life | Working Conditions | Humidity |
|---|---|---|
7/24 - 50.000 hours | Operation Temp. : 0~ 50 °C | Storage Temp. : - 20~60 °C | 10 ~ 80% |
Dimensions
Unit Size(mm) (w x h x d) | Unit Package Size (mm | Product Weight(kg) | Package Weight(kg) | Stand Size (mm) | Stand Package Size(mm) | Stand Weight(kg) |
|---|---|---|---|---|---|---|
911 x 370 x 161 | 980 x 503 x 246 | 30 | 35 | 783 x 100 x 50 | 845 x 475 x 195 | 15 |
Accessories
Audio (optional) | Thermal Printer | 1D/2D Barcode Reader |
|---|---|---|
8Ω, 5W x 2 | 80mm | 640x480p, 30times/sec |
Optional
Floor Stand & Logo & Brand Color Customization |
|---|
OTHER (Included in Package)
Easy Installation Guide, Warranty Document, Power Cable |
|---|
Frequently asked questions
What are the key specifications of Self Checkout Mersin 21.5?
The model specification lists Display size: 21.5; Resolution: 1080 x 1920; Brightness: 500 cd/m². Include the model code and selected screen size when ordering, as other options in the same series may have different specifications. Consider scanning, basket display, payment and receipts together. Provide the checkout software name and version, barcode types and required peripherals. A scanner or printer must be supported by the software as well as fitting physically. Review incorrect scans, cancellation and staff-assistance scenarios within the installation workflow. Match the hardware to the actual store use case and clarify payment equipment and software integration requirements before ordering.
Can a self-checkout kiosk work with my existing checkout system?
Compatibility depends on the checkout software and selected peripherals. Check integration scope using the software name, version, scanner and payment-provider details. Review hardware, software and installation as separate quotation items. Consider scanning, basket display, payment and receipts together. Provide the checkout software name and version, barcode types and required peripherals. A scanner or printer must be supported by the software as well as fitting physically. Review incorrect scans, cancellation and staff-assistance scenarios within the installation workflow. Match the hardware to the actual store use case and clarify payment equipment and software integration requirements before ordering.
What information is needed for a price quotation?
Share the model, quantity and installation location. Specify mounting, content playback or management software and any accessories separately so the hardware and service scope can be compared for your requirements. Consider the available installation space as well as the screen diagonal. A quotation request can include the intended task, daily operating hours, indoor or outdoor location and delivery destination. For multiple sites, list quantities and differing requirements separately so that model options can be compared. Identify any required connection or function that is not shown in the specification. This helps define a comparable equipment proposal rather than a screen price without the installation context.
How should content resolution be selected for Self Checkout Mersin 21.5?
The model specification lists a resolution of 1080 x 1920. Prepare the content pixel dimensions and aspect ratio for this value; use a suitable layout rather than stretching artwork with a different shape. Check that text, prices and logos can be read from the intended viewing distance using sample content. Match the computer or media player’s video output settings to the display specification as well.
What should I verify for kiosk peripherals?
List the printer, reader, computer or payment terminal required by the workflow. Check each component’s physical fit, connection, power requirements and application support. Equipment shown in a product image is not necessarily standard in every configuration. Include the model code and chosen components in the quotation to establish what is supplied and which integrations are required.
What should be tested when receiving a kiosk?
Test the display, touch response, network connection and any selected peripherals with the intended application. Check that users can start and finish the main task and use cancel and help actions. Review cable access and maintenance points with the installation team. This checklist is purchasing guidance; the actual delivery, testing and installation scope should be stated in the quotation.
Application Images
Reviews
There are no reviews yet.
